chook.f File Reference

Go to the source code of this file.

Functions/Subroutines
subroutine	chookbgrun
subroutine	chookbgevent
subroutine	chookobs (aTrack, id)
subroutine	chookenevent
subroutine	chookenrun
subroutine	chooktrace
subroutine	chookeint (never)
subroutine	chookgint (never)
subroutine	chooknepint (never)

Function/Subroutine Documentation

chookbgevent()

subroutine chookbgevent

(

)

Definition at line 37 of file chook.f.

References cqincident(), radiallen, x, xyz, y, and z.

      implicit none

#include "Ztrack.h"
#include "Zmanagerp.h"

      type(track):: inci
      type(coord):: angle
      real*8 rl

!      write(*, *) ' bigin event generation'
      call cqincident(inci, angle)
      rl = inci.pos.radiallen

      write(*,'(6g15.4)')
     *  sngl(inci.vec.w.x),  sngl(inci.vec.w.y), sngl(inci.vec.w.z),
     *  sngl(inci.pos.xyz.x/rl), sngl(inci.pos.xyz.y/rl),
     *  sngl(inci.pos.xyz.z/rl)

Here is the call graph for this function:

chookbgrun()

subroutine chookbgrun

(

)

Definition at line 13 of file chook.f.

References cprintobs(), cprintprim(), and cwriteparam().

      implicit none
#include "Zmanagerp.h"

!         If you feel writing the parameters on stderr is
!         a bother, comment out the next or
!         use other device than ErrorOut.
!         Also you may comment out all output routines below.

!
!            namelist output
      call cwriteparam(errorout, 0)
!            primary information
      call cprintprim(errorout)
!            observation level information
      call cprintobs(errorout)

Here is the call graph for this function:

chookeint()

subroutine chookeint

(

integer

never

)

Definition at line 190 of file chook.f.

            implicit none

#include  "Ztrack.h"
#include  "Ztrackv.h"
!  #include  "Ztrackp.h"

      integer never   ! input & output

!         don't make never = 1, if you want to get
!         information after an electron made interaction
!         if this is made non zero, this routine will never be called.
!
!   MovedTrack is the electron that made interaction
!   Pwork contains produced particles.
!   Nproduced has the number of particles in Pwork
!   IntInfArray(ProcessNo) contains the type of interaction
!
!        default setting
      never = 1
!
!        IntInfArray(ProcessNo).process will have one of
!       'brems', 'mscat', 'bscat'  'anihi' or 'mbrem'
!

chookenevent()

subroutine chookenevent

(

)

Definition at line 115 of file chook.f.

References cwriteseed().

      implicit none
#include "Ztrack.h"
#include "Ztrackv.h"
#include "Zobs.h"
#include "Zobsp.h"
#include "Zobsv.h"
#include "Zmanagerp.h"

      integer i
      if(observeas) then
!                   electron size in B approx.
         write(*, *) (asobssites(i).esize, i=1, noofassites)
!                   size weighted age
         write(*, *) (asobssites(i).age,   i=1, noofassites)
      endif
!        ************ if you want to flesh this event later
!        you may keep the random no. seed  by the following
      if(job .eq. 'skeleton') then
         call cwriteseed        !  SeedFile
      endif

Here is the call graph for this function:

chookenrun()

subroutine chookenrun

(

)

Definition at line 143 of file chook.f.

References cprintstatus().

      implicit none
      call  cprintstatus   ! if don't like,  comment out

Here is the call graph for this function:

chookgint()

subroutine chookgint

(

integer

never

)

Definition at line 219 of file chook.f.

            implicit none

#include  "Ztrack.h"
#include  "Ztrackv.h"
!  #include  "Ztrackp.h"

      integer never   ! input & output

!         don't make never = 1, if you want to get
!         information after a gamma ray made interaction
!         if this is made non zero, this routine will never be called.
!
!   MovedTrack is the gamma that made interaction
!   Pwork contains produced particles.
!   Nproduced has the number of particles in Pwork
!   IntInfArray(ProcessNo) contains the type of interaction
!
!        default setting
      never = 1
!         IntInfArray(ProcessNo).process will have one of
!        'pair', 'comp', 'photoe' 'photop' 'mpair'
!

chooknepint()

subroutine chooknepint

(

integer

never

)

Definition at line 247 of file chook.f.

            implicit none

#include  "Ztrack.h"
#include  "Ztrackv.h"
!  #include  "Ztrackp.h"

      integer never   ! input & output

!         don't make never = 1, if you want to get
!         information after a non-e-g particle  made interaction
!         if this is made non zero, this routine will never be called.
!
!   MovedTrack is the particle that made interaction
!   Pwork contains produced particles.
!   Nproduced has the number of particles in Pwork
!   IntInfArray(ProcessNo) contains the type of interaction
!
!        default setting
      never = 1
!
!        IntInfArray(ProcessNo).process  will have
!             'col' or 'decay'

chookobs()

subroutine chookobs	(	type(track)	aTrack,
		integer	id
	)

Definition at line 62 of file chook.f.

References charge, code, coszenith, and p.

!
!     Note that every real variable is in double  precision so
!     that you may output it in sigle precision to save the memory.
!     In some cases it is essential to put it in sigle (say,
!     for gnuplot).
!
      implicit none
#include "Ztrack.h"
      integer id  ! input.  1 ==> aTrack is going out from
!                                 outer boundery.
!                           2 ==> reached at an observation level
!                           3 ==> reached at inner boundery.
      type(track):: atrack
!
!     For id =2, you need not output the z value, because it is always
!     0 (within the computational accuracy).
!
      if(id .eq. 9) then
!            output typical quantities.

        write(*, *) id,
     *  atrack.where,   !  observation level. integer*2.  1 is highest.
     *  atrack.p.code,    !  ptcl code.  integer*2.
     *  atrack.p.charge,  !  charge,  integer*2
!     *  sngl(aTrack.t), !  relateive arrival time in nsec (NOT sec).
                        !  if TimeStructure is F, nonsense.
!     *  sngl(aTrack.p.fm.p(4)-aTrack.p.mass)  ! total energy in GeV.
!     *  sngl(aTrack.pos.xyz.r(1)), sngl(aTrack.pos.xyz.r(2)), !  x, y in m
!     *  sngl(aTrack.vec.w.r(1)),  ! direc. cos.x in the current detector system.
!     *  sngl(aTrack.vec.w.r(2)),  ! direc. cos.y
!     *  sngl(aTrack.vec.w.r(3)),  ! direc. cos.z
     *  sngl(atrack.vec.coszenith) ! cos of zenith angle
!     *  aTrack.wgt         ! weight of the particle (may not be 1. if
                                 ! ThinSampling =T)
       endif
!         you may need in some case other information such as
!       aTrack.p.subcode   ! sub code of the particle integer*2
!       aTrack.p.mass      ! mass


!       aTrack.p.fm.p(1)      ! momentum x component.  Note. Momentum is
!                            given in the  Earth xyz system.
!       aTrack.p.fm.p(2)      !          y
!       aTrack.p.fm.p(3)      !          z
!               To convert the momentum into the observational
!               coordinate system,  you may call
!       call cresetMom(aTrack)

chooktrace()

subroutine chooktrace

(

)

Definition at line 155 of file chook.f.

References height.

            implicit none

#include  "Ztrack.h"
#include  "Ztrackv.h"
#include  "Ztrackp.h"
#include  "Zobs.h"
#include  "Zobsv.h"

       real*4 h1,  h2
!
!    Every time a particle is moved in the atmosphere, this routine is called,
!    if trace > 100
!         For a one track segment,
!     TrackBefMove  has  track information at the beginning of the segment.
!     MoveTrack    has   track information at the end of the segment.
!
!     You can know the  information a track contains in the
!     chookObs routine. (Note however, no conversion of coordinate
!     has been done.  The values are in the Earth xyz system.)
!     Besides quantities explained there, you can use, for a  given 'track'
!
!     atrack.pos.xyz.x, atrack.pos.xyz.y, atrack.pos.xyz.z    (x,y.z)
!     atrack.pos.radiallen   (distance from the center of the earth)
!     atrack.pos.depth       (vertical depth)
!     atrack.pos.height      (vertical heigth from sea level)
!

      h1 = trackbefmove.pos.height- obssites(noofsites).pos.height
      h2 = movedtrack.pos.height - obssites(noofsites).pos.height
